Visible Spectrophotometer LMSPV320

Product Description

Product Specification

Wavelength Range

325-1000 nm

Optical System

Single Beam

Spectral Bandwidth

4 nm

Model No / Item Code

LMSPV320

Wavelength Accuracy

+-2nm

Wavelength Repeatability

+-1nm

Photometric Accuracy

+-0.5% T

Photometric Range

-0.3-3A,0-200%T

Photometric Repeatability

+- 0.3% T

Stray Light

Less than equal to 0.3%T

Stability

+- 0.002 A/h

Detector

Silicon Photodiode

Lamp Type

Tungsten Halogen Lamp

Grating

1200 lines / mm

Data Output Port

USB Port

Display

LCD

Dimensions

420 x 280 x 180mm

Power

AC 220V/50Hz

Weight

8 kg

Product Description

• MICROPROCESSOR CONTROLLED Microprocessor controlled, LMSPV320 can realize auto Zero and auto 100% T adjustment with one push-button. LMSPV320 has an LCD display for direct readout of Transmittance, Absorption, and Concentration.
• GRATING MONOCHROMATOR LMSPV320 uses 1200 line grating which ensures high resolution, low stray light, and parameters accuracy.
• DATA OUTPUT LMSPV320 is equipped with a USB port that can be connected to a PC to edit data through specific software (Optional) Data can also be printed through a parallel port connected to a micro printer.
• COMPACT DESIGN, EASY TO CARRY The compact design of LMSPV320 saves bench space while all component functions remain performed like a 120mm wide sample compartment and long optical path monochromator.
• DISPLAY MODE LMSPV320 can display absorption, transmittance, concentration, and coefficient directly by different mode switching.
